Linksys LAPAC1200C User Manual

71
Allowed VLAN
List
Enter the list of VLANs accepted by the WDS Root.
When VLAN is enabled, WDS Root receives from WDS
Stations only packets in the VLAN list. Packets not in the
list will be dropped.
The VLAN list is only applicable when VLAN is enabled.
The VLAN list includes 1 to 16 VLAN IDs separated by ","
such as "100,200,300,400,500,600,700,800".
Security
Settings
Setting can be Disabled, WPA-Personal, WPA2-Personal,
WPA2-Enterprise or WPA/WPA2-Enterprise.
WDS Station
Interface
Status
Enable or disable the WDS Station.
Before configuring a WDS Station, be sure the following
settings of the device are identical to the WDS Root that
will be connected.
•
Radio
•
IEEE 802.11 Mode
•
Channel Bandwidth
•
Channel
Note-It is highly recommended that static channel is
configured on both APs. Do not use Auto channel option
when you enable WDS, as both APs in a WDS link must be
on the same radio channel. If Auto option is configured,
there is chance two access points run on different channels
and WDS link cannot establish.
Workgroup Bridge and WDS will not work at the same time
on one wireless radio. When Workgroup Bridge is enabled,
WDS will be disabled automatically on the same radio.
Remote SSID
Enter the name of the Root’s SSID. Click Site Survey
button and choose from the list. You must do this for WDS
Station to connect to a remote WDS Root.

Linksys LAPAC1200C Specifications

General

Color	multi, white
Wi-Fi Speed	1200 gigabits per second
Wireless Standard	ac, n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	802.1x supplicant; mac-based acl; rogue ap detection; ssid-to-vlan mapping
Ports	other, rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.12 pounds
