Linn Kolektor User Manual

3
34
iii
UK USERS PLEASE READ THIS IMPORTANT SAFETY INFORMATION
Fuse replacement
This appliance is fitted with a non-rewireable 13 Amp mains plug. The plug
contains a 5 Amp fuse. If the fuse has blown it can be replaced as follows:
a) Pull out the red fuse cover/carrier.
b) Remove and dispose of the blown fuse.
c) Fit a new 5 Amp BS1362 approved fuse into the carrier and push the
carrier back into the plug.
Always ensure the fuse cover is fitted. If the fuse cover is missing do not use
the plug. Contact your Linn retailer to obtain a replacement fuse cover.
Fuses are for fire protection and do not protect against electric shock.
Mains plug replacement
Should your mains plug need replacing and you are competent to do this
proceed as follows. If you are in doubt contact your Linn retailer or a
competent electrician.
a) Disconnect the plug from the mains supply.
b) Cut off the plug and dispose of it safely. A plug with bared conductors is
dangerous if engaged in a live socket.
c) Only fit a 13 Amp BS1363A approved plug with a 5 Amp fuse.
d) The cable wire colours or a letter will be marked at the connection points
of most quality plugs.
Attach the wires securely to their respective points. The Brown wire must
go to the Live pin, the Blue wire must go to the Neutral pin, and the
Green/Yellow wire must go to the Earth pin.
e) Before replacing the plug top ensure that the cable restraint is holding
the outer sheath of the cable firmly and that the wires are correctly
connected.
WARNING
THIS APPLIANCE MUST BE EARTHED.
Replacing the fuse
Should the mains fuse blow replace it only with an equivalent part. The fuse
holder is located just below the mains inlet socket. To replace the fuse
disconnect the product from the mains supply. Using a flat blade
screwdriver remove and replace the fuse. If the fuse blows a second time
there is a fault in the product. Contact your local retailer.
Fuse ratings. See specifications section.
Mains voltage operating range. See specifications section.
Warning!! The power supply may be destroyed if a unit
designed for 115V is connected to 230V.

Linn Kolektor Specifications

Power

mains input range	100-115 Vac @ 50/60 Hz +/- 10%, 220-240 Vac @ 50/60 Hz +/- 10%
power consumption	8 W maximum
fuse rating	T800mA

Audio Specifications

audio input impedance (Input 1)	47 k Ohms in parallel with 68 pF
audio input impedance (Inputs 2-10)	50 K Ohms
maximum input level	2.5 V rms
nominal input levels (Input 1)	2.5 mV rms
nominal input levels (Inputs 2-10)	2V rms
output impedance (Line output)	300 Ohms
output impedance (Tape output)	100 Ohms
gain (Input 1)	45 dB maximum @ 1 kHz
gain (Inputs 2-10)	10 dB maximum
tape output gain	36 dB from input 1 @ 1 kHz, 0 dB from inputs 2-10
gain control range	60 dB in 1 dB steps
response adjustments (Bass)	+/- 10 dB at 40 Hz
response adjustments (Treble)	+/- 10 dB at 20 kHz

Weight and Dimensions

height	80 mm
width	320 mm
depth	325 mm
weight	4 kg
