Linn Kolektor User Manual

9
30
Technical information
Specifications
General
Dimensions 80mm x 320mm x 325mm
(3.15" x 12.6" x 12.88") (H x W x D)
Weight 4kg
Power consumption 8W maximum
Mains supply fuses 100–115VAC T800mA
220–240VAC T400mA
Mains supply tolerance ±10% with no performance change
Audio
Input impedance Input 1: 47kΩ in parallel with 68pF
Inputs 2 to 10: 50kΩ
Maximum input level 2.5V rms
Nominal input levels Line inputs: 2V rms
Phono (MM) input: 2.5mV rms
Output impedance Line outputs: 300Ω
Tape output: 100Ω
Gain Line inputs: 10dB maximum
Phono input: 45dB maximum at 1kHz
Tape output: 0dB from line inputs
36dB from phono input at 1kHz
Gain control range 60dB in 1dB steps
Response adjustments Bass: ±10dB at 40Hz
Treble: ±10dB at 20kHz
vii
Copyright and acknowledgements
Copyright © Linn Products Limited.
Linn Products Limited, Floors Road, Waterfoot, Glasgow, G76 0EP,
Scotland, United Kingdom.
All rights reserved. No part of this publication may be reproduced,
stored in a retrieval system, or transmitted, in any form or by any
means, electronic, mechanical, photocopying, recording, or
otherwise, without the prior written consent of the publisher.
Printed in the United Kingdom.
KOLEKTOR is a trademark of Linn Products Limited.
The information in this manual is furnished for informational use
only, is subject to change without notice, and should not be
construed as a commitment by Linn Products Limited. Linn
Products Limited assumes no responsibility or liability for any errors
or inaccuracies that may appear in this manual.
This manual was produced by Human-Computer Interface Ltd,
Cambridge, England.
v

Linn Kolektor Specifications

Power

mains input range	100-115 Vac @ 50/60 Hz +/- 10%, 220-240 Vac @ 50/60 Hz +/- 10%
power consumption	8 W maximum
fuse rating	T800mA

Audio Specifications

audio input impedance (Input 1)	47 k Ohms in parallel with 68 pF
audio input impedance (Inputs 2-10)	50 K Ohms
maximum input level	2.5 V rms
nominal input levels (Input 1)	2.5 mV rms
nominal input levels (Inputs 2-10)	2V rms
output impedance (Line output)	300 Ohms
output impedance (Tape output)	100 Ohms
gain (Input 1)	45 dB maximum @ 1 kHz
gain (Inputs 2-10)	10 dB maximum
tape output gain	36 dB from input 1 @ 1 kHz, 0 dB from inputs 2-10
gain control range	60 dB in 1 dB steps
response adjustments (Bass)	+/- 10 dB at 40 Hz
response adjustments (Treble)	+/- 10 dB at 20 kHz

Weight and Dimensions

height	80 mm
width	320 mm
depth	325 mm
weight	4 kg
