• Slide the single nut/bolt (still attached to board) into the middle of its slot – do not tighten
• Rest the board on the heatsink in a central position.
• Line up the screw holes in the board with those in the heatsink and screw in all four screws – but do not
tighten fully.
• Line up the board and heatsink so that they are parallel and level with each other (as diagrams above)
and then tighten the screws fully.
• Tighten the nut/bolt
2. Refit boards into tray – just do the reverse of the dismantling process described at the start of this
document.
3. Refit sleeve
4. Test amp fully
