Linsar WM800 - Water Inlet Hose Connection

28
•Yourmachinemayhaveeitherasingleinlet
(cold)ordoublewaterinlets(cold/hot)basedonits
specications.
Awhite-cappedhoseshouldbeconnectedtothe
coldwaterinletandared-cappedhosetoahot
waterinlet(applicableformachineswithdouble
waterinlets).
•Toeliminatewaterleakagesinpointsofcontact,
1or2nutsareprovidedinthehosepackage(ap-
plicableformachineswithdoublewaterinlets).
Fitthesenutstotheendsofnewwaterinlethoses
onthetapendofthehose.
•Mountnewwaterinlethosestoa¾˝,threaded
faucet.
•Connectthewhite-elbowendofthewaterinlet
hosestothewhite-lteredwaterinletvalveonthe
rearsideofthemachineandthered-elbowendto
red-lteredone(applicableformachineswithdou-
blewaterinlets).
Tightenplasticpartsofthejunctionsusingyour
hand.Inuncertainconditions,havetheconnection
worksdonebyaqualiedplumber.
•Flowofwaterwithpressureof0,1-1Mpawill
allowyourmachinetooperatemoreefciently.)
(0,1Mpapressuremeansthatmorethan8litres
ofwaterwillowthroughafully-tappedfaucetper
oneminute.)
CHAPTER -3: INSTALLATION
(WATER INLET HOSE CONNECTION)
3/4”
10mm
