Linsar WM800 - Water Discharge Connection

30
•Theendofwaterdischargehosecan
bettedtoaspecicapparatusdirectly
attachedtodirtywaterdischargeholeor
outletjointofthebasinelbow.
•Neverattempttoextendthewater
dischargehosebyjointing.
•Donotputdischarginghoseofyour
machineinavessel,bucketorsink.
•Makesurethatthewaterdischargehose
doesnotbend,buckle,becrushedor
extended.Pleasenote:
•Thewaterdrainhoseshouldbemounted
ataheightofminimum60cm,maximum
100cmfromtheground.
CHAPTER -3: INSTALLATION
(WATER DISCHARGE CONNECTION)
~95cm ~140cm
~145cm ~95cm
0–max.100cm
˜
˜
95cm
150cm
