LION alcolmeter 500 - Breath Test Record Printouts

lion alcolmeter
®
500 Mk IV User Handbook
22
4: Breath Test Record Printouts
Assuming a printer is connected to your 500 then at the end of breath
analysis procedure the instrument will automatically switch it on and
generate a relevant printed record.
In the first printout example [shown on page 28], at 12:37:06 on 01
March 2012 the subject provided a valid specimen of breath into the
500. This was analysed and found to contain alcohol at a level of
0.65mg/L. In the second example, on 01 March 2012 the subject
blew three [3] times into the 500, but none of these were sufficient for
analysis. At 14:01:10 the operator terminated the procedure by
pressing FSA to log the fact that the subject had failed to provide a
suitable specimen of breath for analysis.
There is space on the document for additional details [of the
operator, subject, test witness and location] all to be entered by hand.
Additional copies may be obtained by calling up the RECALL LAST
TEST option in the menu that appears at the end of the test.
Connect the printer when LAST TEST RECALL is flashing, then
press Select. The printer turns on automatically.
The printer uses rechargeable batteries only: these are recharged
using a different charger system to that used with the rechargeable
power supply option in the instrument itself.
