T
o select a single operational state for
your locomotive (example: forward
only), you can deactivate the Command
reverse unit’s sequencing function with the
reverse unit switch.
Get your powered locomotive moving in
the desired direction, then slow it down
without stopping. Set the Command reverse
unit switch to PR0G/LOCK. Refer to Figure 1
for the location of the switch. The
locomotive is now “locked” into your chosen
direction.
When you no longer want single-direction
operation, just slide the Command reverse
unit switch back to FWD/RUN.
Your locomotive’s reverse unit will
“reset” to forward after any five
second or longer power
interruption, regardless of the
original locked-out direction.
Locking your locomotive into a single operational state
Transformer operations
Figure 1. Switch locations
4
Note!
PROG/LOCK
FWD/RUN
Command
reverse unit
switch
