Lionel F-3 B-Unit - Building a Lash-Up

T
o build a lash-up, assign a unique engine (ENG) ID# to each unit. Arrange the units on
the track and couple them together. The Command reverse unit switches must be set to
FWD/RUN.
If you press a wrong button, start over with that particular unit; the assignment isn’t
saved until you press SET on the CAB-1.
Start with the lead powered unit.
1. On your CAB-1 Remote Controller, press TR, then enter your lash-up ID# (1-9).
No other track or lash-up should be assigned that ID#.
2. Enter the lead unit’s unique ID#, then press F.
3. Press SET beneath the front panel of the CAB-1.
The lights will flash to indicate that the lead locomotive has been assigned the first
position.
Add the powered F-3 B-unit.
1. On your CAB-1 Remote Controller, press TR, then enter your lash-up ID# (1-9).
2. Enter the powered F-3 B-unit’s unique ID#, then press R to activate the back-up light.
If you choose to add an additional unit to create an A-B-A lash-up and want to de-
activate the back-up light, do not press R.
3. Press SET beneath the front panel of the CAB-1.
Add the rear unit (backward-facing A-unit in an A-B-A lash-up).
1. On your CAB-1 Remote Controller, press TR, then enter your lash-up ID#
2. Enter the rear unit’s unique ID#, then press R.
3. Press the DIR to indicate that this unit is facing the end of the train.
4. Press SET beneath the front panel of the CAB-1.
Building a lash-up
Note!
Note!
TrainMaster Command operations
9
Note!
