Rev: 02.25.21 Page 3 CCD-0004124
Operation
Moving parts can pinch, crush or cut. Keep clear and use caution.
Release Steps
1. From the stowed position (Fig. 1), disengage the transport lock (Fig. 1A) by pulling the transport lock
knob to the right.
2. Firmly grasp and pull out the vertically stored SolidStep XF and rest it firmly on the ground.
3. Adjust leg extensions as needed. See Leg Extension Adjustment section.
Fig. 1
A
B
