Rev: 06.09.20 Page 10 CCD-0002734
B. Install a stem sensor onto the tire stem in the proper sequence (Fig. 14) and wait for the smart
phone to indicate the sensor was found(Fig.15A).
NOTE: It may take up to 30 seconds for the sensor to wake and be found.
C. If the sensor is not seen within 30 seconds, unscrew the sensor from the tire stem, wait
approximately 10 seconds and then reinstall the sensor. Do not proceed to install any other
sensors until the app shows the sensor is found.
D. After the sensor has been found, the app will indicate the next tire sensor to be paired (Fig.15B).
E. Repeat step 4B, 4C and 4D until all sensors are learned (Fig.15).
5. Press the FINISHED button (Fig.16A) to exit TIRE PRESSURE Sensor Configuration mode.
Pressing FINISHED exits configuration mode and redisplays the Tire Pressure screen. DO NOT press the
LEARN SENSORS button. Doing so resets Tire Linc into configuration mode, which requires uninstalling the
Stem Sensors.
NOTE: When learning has been completed, the low and high pressure limits of the tires are estimated at
+/- 20% of the last received sensor data. Make sure sensors are not removed during the learning
process or the pressure limit values will be incorrectly estimated. Pressure and temperature limits
can be set through the app after learning has been completed.
NOTE: If installing the optional lock nuts as a theft deterrent, loosen stem sensor slightly and hand tighten
lock nut against the sensor. Using the wrench provided in kit, hold lock nut in position and hand
tighten stem sensor against lock nut.
Fig. 13
Fig. 14
Fig. 15
Fig. 16
A
A
A
B
