Rev: 06.09.20 Page 2 CCD-0002734
TABLE OF CONTENTS
Introduction 2
Key System Components 2
Safety 4
Preparation 4
Pairing Alert Indicator to Repeater 4
Connect OneControl App to Repeater 6
Stem Sensor Pairing Sequence 9
Pairing Stem Sensors to Repeater Via Smart Phone 9
Pairing Stem Sensors to Repeater Via Alert Indicator 11
Operation 12
Alert Indicator 12
OneControl App 12
Tire Limits Example 14
Troubleshooting 15
Remove Stem Sensor to Change Battery 15
Factory Reset 15
No Power 15
Learn Sensors Procedure Resets System 15
Introduction
Tire Linc® is a tire pressure and temperature monitoring system (TPMS). The TPMS issues an alert via the
OneControl® app or the Alert Indicator when a trailer’s tire(s) pressure or temperature falls out of the
programmable range.
Key System Components
Refer to figure 1 for the following components:
Sensors - Stem Mount, 188 psi maximum pressure reading, -58 to 401 °F (-50 to 205 °C) temperature
measurement range with two ways to monitor tire conditions; OneControl app and Alert Indicator.
Repeater - Receives sensor data, communicates with Alert Indicator and Phone App via Bluetooth Low
Energy(BLE).
Repeater Dock - Provides power to repeater, which “docks” to this base.
Alert Indicator - Battery powered: Can be charged via USB Micro B connector; lights LED and beeps on tire
faults, e.g., pressure high/low, temperature high/low, sensor battery.
OneControl App - Displays real-time tire pressures, temperatures and visual alerts for faults.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/tire-linc.
