Lippert Ground Control 3.0 LCD - Page 10

Rev: 05.20.2022 Page 10 CCD-0001745
Fig. 13
A
Fig. 14 Fig. 15
A
Bottom of Jack Motor Override
Resources Required
•
⁄
” drive ratchet and extension
•
⁄
” socket
Procedure
1. Find the port on the bottom of the jack motor (Fig. 13A).
2. Unplug 2-pin motor harness.
3. Remove the rubber plug (Fig. 14A).
4. Insert the
⁄”
socket into the port (Fig. 15A).
5. Turn clockwise on override until the jack extends or turn counterclockwise on override until retracts to
the desired position.
6. Plug in 2-pin motor harness connector.
NOTE: After any Landing Gear or Hall Effect Jack has been manually overridden, the system will need to be
serviced and the jacks will need to be homed. See Homing Jacks section.
A
