Rev: 05.20.2022 Page 24 CCD-0001745
6-Point Wiring Diagram
Battery
Hall Effect Landing Gear Hall Effect Landing Gear
Rear Sensor
Rear Sensor
Harness
LCD Touchpad
Touchpad Harness
6-Point
Controller
Hall Effect Jack Hall Effect Jack
Hall Effect Jack
Hall Effect Jack
Recommended
50 Amp Breaker
(OEM Supplied)
