Rev: 05.20.2022 Page 23 CCD-0001745
4-Point Wiring Diagram
Hall Effect Landing Gear
LCD Touchpad
LCD Touch
Pad Harness
Recommended
50 Amp Breaker
(OEM Supplied)
Hall Effect Landing Gear
Hall Effect
Harness
Hall Effect
Harness
Hall Effect
Jack
Hall Effect
Jack
Battery
4-Point Controller
Rear Sensor
Rear Sensor
Harness
