11
2.3. Technical data
MULTICUT 800 G MULTICUT 800 GH
Cut depth 315 mm (515 mm) 315 mm (515 mm)
Cutting depth setting Electrohydraulic / variable Electrohydraulic / variable
Standard saw blade Ø 800 mm (1,200 mm) 800 mm (1,200 mm)
Saw blade holder 35 mm (6x M12-TK 120 mm) 35 mm (6x M12-TK 120 mm)
Drive forwards 0 - 60 m/min 0 - 60 m/min
Drive backwards 0 - 25 m/min 0 - 25 m/min
Max. Output power 44 kW/ 60 PS 44 kW/ 60 PS
Saw blade speed Standard 1550 / 970 RPM 1550 / 970 RPM
Saw blade speed Optional 2500 / 1550 RPM 2500 / 1550 RPM
Saw blade drive V belt drive V belt drive
Dimensions (L/W/H mm) 1680 / 1050 / 1360 1680 / 1050 / 1360
Weight 935 kg 1070 kg
2.4. Noise parameters
Guaranteed noise power level:
MULTICUT 800 G MULTICUT 800 GH
113 dB(A) 113 dB(A)
Danger
Hearing protection must be worn when exceeding 85 dB(A)!
The noise emissions measurement was performed in
compliance with ISO 4872 DIN/ISO 6393 and DIN/ISO 6394.
2.5 Vibration on the steering shaft
Operating condition:
Measurement during concrete cutting
Blade diameter 1000m, Cutting depth 100mm
Total oscillation value
ahv = 5.47m/s²
The following standards were complied with during
measurement:
ISO 5349, DIN ENV 25349, DIN 45671, VDI 2057
The given values were measured during concrete cutting at a
cut depth of 10cm. In practice, these values are influenced by
the following conditions:
Quality of the saw blade
Weight of the operator
Feed speed
Condition of the machine
Concrete properties
