7.2 Operating materials
Diesel motor, see Kubota operating manual
Drive oil for the bevel gear drive (Pos. 52)
* SAE 90 fully synthetic 1.2 l
Lubrication points
* Roxana ALU EP2
7.3 Lubrication points
Moving parts must be lubricated using the integrated
lubrication nipples. The lubrication points are marked and
covered by red dust caps.
Only use qualified heat-resistant multi-purpose grease.
Roxana ALU EP2 multi-purpose grease is used.
Lubrication points and guides
Lubricate the guide columns (Pos. 46) weekly
Lubricate the support bearings (Pos. 47.1) weekly
Lubricate the saw blade shaft (Pos. 47) weekly
Lubricate steering parts (Pos. 45) weekly
Lubricate the rigid axles of heavy duty wheels monthly
47.1
46
47
45 45 45
