27
7.4 Hydraulic oil change
The system (Pos. 48) is filled with "BP Batran HVAC-68"
hydraulic oil by the manufacturer. Old oil can be exhausted at
the filling neck of the system.
You can also screw off the system and tip it so that the oil
runs out.
7.5 Bevel gear drive oil change (Pos. 52)
Remove the cover plate (Pos.50)
Screw the ventilation stopper out (Pos. 53)
Remove the drain screw (Pos. 51)
Drain oil
Return the drain screw (Pos. 51)
Refill oil (SAE 90 fully synthetic 1.2l)
45 54 45 61 48 56
