Lite-Check INSPECTOR 920 - Keyboard and Controls

LITE-CHECK INSPECTOR 920
Page 10 of 36
Item Description
7-Way Cable Socket Cable socket for 7-way cable
7-Way Cable Socket (for testing) Cable socket for 7-way cable. (Used for cable
testing)
Keyboard Layout
The chart below provides a brief description of each button on the keyboard panel and
on the remote control.
Graphic
Panel
Button
Remote
Button Function
EMER.
EMER. EMER. Operates emergency air
SERVICE SERVICE Operates service air (if emergency Is
pressurized)
AIR LEAK
TEST
AIR LEAK
TEST
Blocks air source for vehicle air leak test
BRAKE
BRAKE BRAKE Operates brake electrical circuit
MARKER MARKER Operates marker (clearance) circuit
AUXIL
AUXIL AUXIL Operates auxiliary circuit (ABS power)
LEFT LEFT Operates left turn circuit
TAIL TAIL Operates tail circuit
