DX-610/626[EUM-

]
3

Chapter1.  Introduction
1-1  Feature                                                      
 6dimmingchannels.
 Autotrackingoffrequencyandphase.
 Temperaturecontroldevice:Whenthetemperatureisover45āthefanwill
startautomatically.
 Auto tracking of frequency: Enables stable dimming output in different
frequencies. 
 Testingfunction:Candotestwithoutconnectingaconsole. 
 Warm-upfunctiontoprotecttheloads.(Warm-upsetting0---6.0%)
1-2  BriefDeviceIntroductions                                     
 DX-610:10Anofusebreaker.
DX-626:25Anofusebreaker.

Fanfortemperaturecontrollingtosinkheatand
cleanthedustinside.(37CFMX1)
 Thefrontpanelcanbedismantledeasilyfor
quickrepair.


1-3  Specification                               
Power                    AC90-240V,45-63Hz,3Ø4W,1Ø2W 
Output                    DX-610:Maximaloutputis10Aeachchannel 
DX-626:Maximaloutputis20Aeachchannel
                        (Pleaserefertotheusermanual)
DMXsignaloutput/input    DMX512/1990
DMXsignalconnector       XLR5Pin,RJ11-6p4cphonejack
Analogsignalpowerinput    DC0-10V
Analoginputchannel        6channels 
                           PIN1~6CH1~6,PIN7NC  
                           PIN8V+12VOUT,PIN9GND
Analogsignalconnector    D-TypePlug9Pin(F)
Dimension                482(W)x88(H)x300(D)mm
Location                   19"2Ustandardrack
Weight                    8Kg
