Chapter2.  Operation
2 - 1   StandardDMX512Signal                        



2 - 2   DMXStartAddressSetting                   

STEP-1holdingDMX,press▲or▼tofindthestartaddress. 
▲:move1numberforward:uptoChannel512.
▼:move1numberbackward:downtoChannel1.

2 - 3   Dimming/SwitchingSetting                  
        
STEP-1pressDMXkeyintoDMXstatus.
STEP-2pressandholdtheFNCkeyfor3sec.

STEP-3pressFNCkeytoselectchannel.
STEP-4press▲or▼toselectdimmingmodeorswitchingmode.
DX-626isa6channeldimmerpacksowhensettingthisunit:
1 asd.001,  theoutputisfromChannel1Channel6.
2 asd.007,  theoutputisfromChannel7Channel12.
3 Itisallowedforsettingmorethan1pieceofDX-626atthesamestart
address.

DefaultsettingAllchannelare
dimmingmode
Thispointisflashingwhen
receivingDMXsignal. 
