DX-610/626[EUM-

]
5

AMERICANTYPE
Output sockets (DX-610: 10A each channel; DX-626: 15A each channel, e
xternal
powernofusebreakerisnecessarywhenmounting.)

SCHUKOTYPE
Output sockets (DX-610: 10A each channel; DX-626: 16A each channel, e
xternal
powernofusebreakerisnecessarywhenmounting.)

1-6  WiringDiagram                                               

PS.:  Thereare‘3PHASES3WIRES’and‘SINGELPHASE3WIRES’asoption.


