LG WalkAble Assembly
Tools Required:
Scissors
1/2 inch socket or open-end wrench
5/16 inch Allen wrench (provided)
LiteGait® KW Assembly Instructions:
Read below & follow pictures.
NOTE: Two people are required for safe assembly.
NOTE: Your LiteGait® may look different than the following
images, but assembly Steps are the same.
1.) Inspect shipment and note any visual
damage to box and/or crate
2.) Open carton carefully, using utility
knife to cut the tape that seals the box.
3.) Remove the post from the box and
carefully cut away package material.
4.) Open larger inside box containing the
yoke and handles bars. Carefully cut
away package material
6.) Remove the base from the box and
place on a level floor.
7.) Prepare remaining parts for
assembly by removing remaining
packaging material.
8.) Lock all four casters to make base
stationary and remove the bolts from
the top plate on the base.
9.) Lift the main post and align post
plate with holes on base plate.
5.) Remove and open soft goods. Soft
goods box should contain at least one
harness wrap, two groin pieces and four
overhead straps.
10.) Insert four bolts to attach post to
base plate. Tighten until snug using
7/32” Allen wrench (included).
NOTE: If you have any questions during installation, please
contact Mobility Research Service & Parts Department for
NOTE: Your LiteGait® may look different than images above
