LiteOn EVO600043S2D2E20F Quick Start Guide

45
Parameter
Name
Description
Setting Range
b5-25
PID Target Display
Digits
Sets the number of decimal places to display.
0 ∶ No Decimal Places
1 ∶ 1 Decimal Place
2 ∶ 2 Decimal Places
3 ∶ 3 Decimal Places
Determined by b5-19
Min.: 0
Max.: 3
b5-26
<7>
Frequency
Command Display
During PID
0 : Displays frequency command after the PID
compensation
1 : Displays frequency command before the PID
compensation.
Default∶ 0
Range: 0, 1
b5-27
<7>
PID Output
Direction
Sets the direction when PID output value is
minus.
0 : Reverse is not allowed
1 : Reverse is allowed
Default∶ 1
Range: 0, 1
b5-28
PID Disconnection
Output Frequency
When a PID feedback disconnection alarm
occurs, the drive will run at the frequency set to
b5-28, and return to PID control when
disconnection alarm is reset.
Default: 30.0 Hz
Min.:0.0Hz
Max.: Determined by
d1-02, L2-00, d1-13
b5-29
<7>
PID Wake-up Level
Sets the PID Wake-up level
Default:0.0 Hz
Min.:0.0 Hz
Max.:<5>
b5-30
<7>
PID Wake-up deley
time
Sets the PID Wake-up delay time
Default: 0.0 s
Min.: 0.0 s
Max.: 25.5 s
Group C, Tuning
C1: Acc./Dec. Time
C1-00
<4>
Acceleration Time
1
Sets the time that the drive accelerates from
0Hz to the maximum output.
Default∶ 10.0 s
Min.: 0.0 s
Max.: 6000 s
C1-01
<4>
Deceleration Time
1
Sets the time that the drive decelerates from the
maximum output to 0Hz.
C1-02
<4>
Acceleration Time
2
Sets the time that the drive accelerates from
0Hz to the maximum output.
C1-03
<4>
Deceleration Time
2
Sets the time that the drive decelerates from the
maximum output to 0Hz.
C1-08
Fast Stop Time
Sets the time to stop the drive faster.
Default: 10.0 s
Min.: 0.0 s
Max.: 3600 s
C1-11
Jog Acc. Time
Sets the time to accelerate from 0 Hz to Jog
Frequency Command (L1-16).
Default: 10.0 s
Min.: 0.0 s
