LiteOn EVO600043S2D2E20F Quick Start Guide

44
Parameter
Name
Description
Setting Range
b5-13
PID Feedback Low
Detection Time
Sets the PID feedback time used for detection.
When the PID feedback falls below the level set
to b5-12 for longer than this time, PID feedback
loss will be detected.
Default∶ 1.0 s
Min.: 0.0 s
Max.: 25.5 s
b5-14
PID Sleep Start
Level
Sets the PID level to trigger the drive to sleep.
Default∶ 0.0Hz
Min.: 0.0 Hz
Max.: <5>
b5-15
PID Sleep Delay
Time
Sets the delay time used to activate/deactivate
the PID Sleep function.
Default∶ 0.0 s
Min.: 0.0 s
Max.: 25.5 s
b5-16
PID Command
Acc./Dec. Time
Sets the PID command acceleration
/deceleration time used for PID target.
Default∶ 0.0 s
Min.: 0.0 s
Max.: 6000 s
b5-17
PID Target
Selection
0 ∶PID Target Disabled
1 ∶PID Target Enabled
Default∶ 0
Range: 0, 1
b5-18
PID Target Value
Sets the PID target value as a percentage of the
maximum output frequency when b5-17 is set
to 1. Disabled when b5-17=0
Default∶ 0.00%
Min.: 0.00%
Max.: 100.0%
b5-19
PID Target Value
Units
0 ∶ 0.01Hz
1 ∶ 0.01% (Maximum Frequency is 100%)
2 ∶ r/min. (Number of Motor Poles must be set)
3 ∶ User Defined (Defined by b5-24 and b5-25)
Default∶ 1
Range: 0, 1, 2, 3
b5-20
PID Output Min.
Sets the lower limit as a percentage of the
maximum output frequency set in d1-02 for
PID output.
Default∶ 0.0%
Min.: -100.0%
Max.: 100.0%
b5-21
PID Input Limit
The higher PID Input value is, the higher PID
output value will be. Sets this parameter to limit
the PID input value.
Default∶ 1000%
Min.: 0.0%
Max.: 1000%
b5-22
PID Feedback High
Detection Level
Sets the level for PID feedback high detection as
a percentage of the maximum output
frequency.
PID feedback high will be detected when the
feedback exceeds the level set in b5-22 for
longer than the time set in b5-23.
Default∶ 100%
Min.: 0%
Max.: 100%
b5-23
PID Feedback High
Detection Time
Sets the time for PID feedback high detection.
PID feedback high will be detected when the
feedback exceeds the level set in b5-22 for
longer than the time set in b5-23.
Default∶ 1.0 s
Min.: 0.0 s
Max.: 25.5 s
b5-24
PID Target Display
Value
Sets a value to display to U4-00 and U4-03
when the drive runs at the maximum output
frequency
Determined by b5-19
Min.: 1
Max.: 9999
