LiteOn EVO600043S2D2E20F Quick Start Guide

43
Parameter
Name
Description
Setting Range
b5-05
<4>
PID Output Limit
Sets the maximum output from PID control as a
percentage of the maximum frequency.
Default∶ 100.0%
Min.: 0.0%
Max.: 100.0%
b5-06
<4>
PID Bias Voltage
Adjustment
Sets the PID bias voltage adjustment as a
percentage of the maximum frequency to add
to the PID control output.
Default∶ 0.0%
Min.: -100.0%
Max.: 100.0%
b5-07
<4>
PID Primary Delay
Time
Sets the delay time for the PID output filter.
Default∶ 0.00 s
Min.: 0.00 s
Max.: 10.00 s
b5-08
PID Output
Selection
0 ∶ Normal PID Output
1 ∶ Reverse PID Output
Reverses the +/- sign of the PID output
Default∶ 0
Range: 0, 1
b5-09
PID Output Gain
Sets a PID output gain
Default∶ 1.00
Min.: 0.00
Max.: 25.00
b5-10
PID Output Reverse
Selection
Determines whether or not a negative PID
output reverses the drive rotating direction
.
0 : Reverse Disabled
1 : Reverse Enabled
Default∶ 0
Range: 0, 1
b5-11
PID Feedback Low
/High Detection
Selection
0 ∶ Multi-Function Output Only
1 ∶ Feedback Low /High Alarm
The drive continues operation when an alarm
is displayed)
2 ∶ Feedback Low /High Fault
A fault will cause the drive to stop the motor.
3 ∶ Multi-Function Output only when PID is
Disabled
Same action as b5-11=0.
4 ∶ Feedback Low /High Alarm (detection
disabled when PID is disabled)
5 ∶ Feedback Low /High Fault (detection
disabled when PID is disabled)
6 : Multi-Function Output (Keep running
without an alarm displayed)
7 : Multi-Function Output Only (detection
working when drive running or not)
Min∶ 0
Max∶ 7
b5-12
PID Feedback Low
Detection Level
Sets the PID feedback level used for detection.
When the PID feedback falls below this level for
longer than the time set to b5-13, PID feedback
loss will be detected.
Default∶ 0%
Min.: 0%
Max.: 100%
