LiteOn EVO600043S2D2E20F Quick Start Guide

42
Parameter
Name
Description
Setting Range
b3-05
<7>
Search speed in V /
f
In order to reduce the speed of search output
current by the V / f curve calculated by
multiplying the voltage set value b3-05 by
adjusting the setting, the speed can be
suppressed search output current.
Default: 100%
Min.: 10 %
Max.: 100%
b4：Timer Function
b4- 00
<7>
Timer Function On-
Delay Time
Sets the on-delay and off-delay time to switch
on/off the timer output.
Default∶ 0.1 s
Min.: 0.1 s
Max.: 3000.0 s
b4- 01
<7>
Timer Function Off-
Delay Time
Default∶ 0.1 s
Min.: 0.1 s
Max.: 3000.0 s
b5: PID Control
b5-00
PID Control Setting
0 ∶ PID Control Disabled
1 ∶ PID Control Enabled (D Control for Deviation
Signal U4-01)
2 ∶ PID Control Enabled (D Control for Feedback
Signal U4-05)
3 ∶ PID Control Enabled (Frequency Command＋
PID Output from D Controlled Deviation)
4 ∶ PID Control Enabled (Frequency Command＋
PID Output from D Controlled Feedback)
5 : PID Control Disabled，but b5-14/b5-15 (PID
Sleep) and b5-29/b5-30(PID Wake-up)
Enabled
Default∶ 0
Min.: 0
Max.: 5
b5-01
Proportional Gain
Setting (P)
Sets the P gain for PID input.
Default∶ 1.00
Min.: 0.00
Max.: 25.00
b5-02
<4>
Integral Time
Setting (I)
Deviation appears between PID target value and
feedback value when using only proportional
control. To reduce the deviation, set integral
time (I).
Default∶ 1.0 s
Min.: 0.0 s
Max.: 360.0 s
b5-03
<4>
Integral Time (I)
Limit Setting
Sets the maximum output from the I (integral)
control as a percentage of the maximum
frequency (d1-02)
Default∶ 100.0%
Min.: 0.0%
Max.: 100.0%
b5-04
<4>
Derivative Time (D)
Sets derivative time for D control.
Default∶ 0.00 s
Min.: 0.00 s
Max.: 10.00 s
