LiteOn EVO600043S2D2E20F Quick Start Guide

41
Parameter
Name
Description
Setting Range
b1-12
Local/ Remote
switching Enable
during Operating
0 ∶Disabled
1 ∶Enabled
Default∶ 0
Range: 0, 1
b1-13
Forward and
Reverse Selection
from Keypad
0 ∶Disabled
1 ∶Enabled
Default∶ 0
Range: 0, 1
b2: DC Braking
b2-00
Zero Speed
Holding (DC
Braking) Start Level
Sets the start frequency for Zero Speed Holding
(DC braking). Enabled when b1-02 (Stopping
Method Selection) is set to 0 (Ramp to Stop)
Default∶ 0.5Hz
Min.: 0.0 Hz
Max.: d1-02
b2-01
DC Braking Current
Sets the DC braking current as a percentage of
the drive rated current
Default∶ 0%
Min.: 0%
Max.: 100%
b2-02
DC Braking Time at
Start
Sets the DC braking time at start to stop a
coasting motor before restarting it or to apply
braking torque at start when high starting
torque is needed.
Disabled when set to 0.00.
Default∶ 0.00 s
Min.: 0.00 s
Max.: 99.99 s
b2-03
DC Braking Time at
Stop
Sets the DC braking time at stop to stop a
motor rotating with high inertia.
Disabled when set to 0.00.
Default∶ 0.00s
Min.: 0.00 s
Max.: 99.99 s
b3: Speed Search
b3-00
Speed Search
Setting
0 ∶Disabled
1 ∶Enabled and searched from the highest
frequency
2 ∶ Enabled and searched from the frequency
command
Default: 0
Range: 0, 1, 2
b3-01
Speed Search
Operating Current
Sets the current level as a percentage of the
drive rated current below which Speed Search is
deactivated.
Default: 120%
Min.: 30 %
Max.: 140%
b3-02
<7>
Voltage Rocevery
Time
Sets the search speed in the output voltage
restoring to the time set v / f voltage curve
required
Default∶ 0.6s
Min.: 0.3s
Max.: 5.0s
b3-04
<7>
Speed search
deceleration time
Sets the search speed in the deceleration time
(The maximum output frequency to the
minimum output frequency deceleration time)
Default∶ 2.0s
Min.: 0.1s
Max.: 10.0s
