LiteOn EVO600043S2D2E20F Quick Start Guide

64
Group F, Optional Function Group
F1: Pump function
Parameter
Name
Description
Unit
F1-00
User pressure sensor
specification setting
According to the pressure sensor specification
(max. feedback voltage or pressure value
corresponding to feedback current)
Default: 10.0
Min.: 0.0
Max.: 10.0
Unit: 0.1bar
(kg/cm2)
F1-01
(Switch mode)
pressure operation
In the switch mode, the inverter automatically
controls the pump to start or stop according to
the set value.
*When the set value is greater than the target
value, the stop level is the target pressure, and
the starting level is 0.
Default: 0.3
Min.: 0.1
Max.: 10
Unit: 0.1bar
(kg/cm2)
F1-02
(Switch mode)
detection time
setting
Set the percentage of time and calculate the
detection time to determine whether to enter the
switch mode.
Set value 0: Switch mode function is OFF.
Default: 40
Min.: 0
Max.: 100
Unit: 1%
F1-03
(Water detection)
pressure rise level
Raise a specified pressure level to detect if water
is currently being used.
Default: 0.2
Min.: 0.1
Max.: 1.0
Unit: 0.1bar
(kg/cm2)
F1-04
(Water detection)
pressure rise time
“limit”
Set the lifting time “limit” of F1-03 (pressure
rise level) to detect whether water is currently
used.
Set value 0: This function is OFF
Default: 0
Min.: 0
Max.: 25
Unit: 0.1 sec
F1-05
(Water detection)
pressure rise interval
Set the time interval of F1-03 (pressure rise level)
to detect whether water is currently used.
Set value 0: Water detection function is OFF
Default: 35
Min.: 0
Max.: 250
Unit: sec
F1-06
(Water detection)
inverter standby
(sleep) level
When the inverter running frequency is lower
than the set value, it will automatically decelerate
to 0 Hz and enter the standby (sleep) state.
Default: 5Hz
Min.: 0
Max.: 60
Unit: 1Hz
