65
F1-07
PID control recovery
level setting
When the inverter is in the standby (sleep) state,
when the pressure drops to the recovery level,
the inverter starts and enters the PID control
mode.
Recovery level: Set pressure (SV) F1-07 set value.
*When the set value is greater than the target
pressure, the recovery level is 0 Hz.
Default: 0.3
Min.: 0.0
Max.: 10.0
Unit: 0.1bar
(kg/cm2)
F1-08
PID steady state
tolerance
Provide error range to determine whether PID
control has reached stability.
Default: 0.1
Min.: 0.1
Max.: 0.5
Unit: 0.1bar
(kg/cm2)
F1-09
(Water shortage
detection) pressure
level
100% is the target pressure, set value 0 is OFF.
Default: 40
Min.: 0
Max.: 100
Unit: 1%
F1-10
(Water shortage
detection) current
level
Set the current level to detect if the pump is in a
water shortage state.
100% is the rated current of the motor, set value 0
is OFF.
Default: 0
Min.: 0
Max.: 100
Unit: 1%
F1-11
(Water shortage
detection) detection
time
Set F1-09 pressure and F1-10 current detection
time.
Default: 60
Min.: 0
Max.: 250
Unit: 1 sec
F1-12
(Fault restart)
downtime interval
Shutdown time of the pump in the absence of
water.
Default: 10.0
Min.: 0.5
Max.: 600.0
Unit: 0.1 sec
F1-13
(Fault restart) restart
function selection
The way the pump is started again in the absence
of water:
0: FBPL warning flashes, does not jump off
1: FBPL fault trips stop, press RESET to restart
2: FBPL fault trips stop, re-power and restart
3: FBPL fault trip stop, waiting F1-12 sets the
interval time, it automatically restarts. After the
restart is completed, you must re-power on the
reply.
Default: 3
Min.: 0
Max.: 3
Unit: -
Group U, Monitor Settings
U1: Status Monitors
U1-00
Control Method
0 ∶ Open-Loop V/F Control
-
