LiteOn EVO600043S2D2E20F Quick Start Guide

66
2 ∶ Sensorloess Voltage Vector Control (SVVC )
(Open-Loop)
U1-01
Frequency
Command
Displays the frequency command. (Display units
are defined by o1-00)
-
U1-02
Output Frequency
Displays the output frequency. (Display units are
defined by o1-00)
-
U1-03
Output Current
Displays output current.
0.01A
U1-04
Motor Speed
Displays the motor speed.
-
U1-05
Output Voltage
Command
Displays the drive output voltage command.
0.1V
U1-06
Main circuit DC
Voltage
Displays the main circuit DC voltage.
0.1V
U1-07
Output Power
Displays the internal output power calculated by
the drive.
0.001kW
U1-09
Input Terminal Status
Displays the status of the input terminal.
U1-09=C111111:
The following indicate each digit from right to
left.
1:Digital Input 1 (S1 enabled )
1:Digital Input 2 (S2 enabled )
1:Digital Input 3 (S3 enabled )
1:Digital Input 4 (S4 enabled )
1:Digital Input 5 (S5 enabled )
1:Digital Input 6 (S6 enabled )
-
U1-10
Output Terminal
Status
Displays the status of the output terminal.
U1-10=1
Multi-Function Terminal Output (terminal
R1A/R1B-R1C)
-
U1-11
Drive Operation
Status
Displays the status of the drive operation.
U1-11=11111111
The following indicate each digit from right to
left.
1:During Run
1:During Zero Speed Holding
1:During Reverse
1:During Fault Reset Signal Input
1:During Speed Agree
1:Drive Ready
1:During Alarm Detection
1:During Fault Detection
-
U1-12
Terminal A1 Input
Voltage
Displays the terminal A1 input voltage.
0.1%
U1-16
Software Version
Displays the software version.
-
U1-19
Communication card
Communication card software version
-
