LiteOn EVO600043S2D2E20F Quick Start Guide

80
Keypad
Display
Fault Name
Cause
Possible Solution
external baseblock
signal
input terminals (S1
to S6)
oH2
Drive Overheat
Warning
Drive Overheat
Warning input via
a multi-function
input terminal
(S1to S6 ) when
E1-口口= 40
An overheat
warning in the drive
was triggered by an
external device
1. Search the device which caused the
overheat warning. Remove the cause of the
problem.
2. Reset Drive Overheat Warning input at the
assigned multi-function input terminal (S1 to
S6)
HCA
Current Alarm
Drive current
exceeded the level
of over current
warning (150% of
the rated current)
1. The load is too
heavy
2. Deceleration and
acceleration times
are too short
3.The drive is
attempting to run a
motor greater than
the maximum
allowable capacity,
or a special-
purpose motor is
being used
4.The current level
went up because of
Speed Search while
attempting to
perform a fault
restart or after a
momentary power
loss
1. Reduce the load or use a drive of higher
rating
2. Calculate the torque required during
acceleration and the inertia
»Take the following steps if the torque level is
not right for the load
· Increase the settings for acceleration and
deceleration time (C1-00 to C1-03)
· Use a drive of higher rating
3. Check the motor capacity
· Make sure the motor capacity is right for the
drive rating.
4. During a momentary power loss or an
attempt to reset a fault, the alarm is displayed.
However, there is no need to take any action
because the fault display will disappear shortly
DNE
Driver Enable
1. Multi-function
contact input is set to
69/169, but the
contact input status is
incorrect
2. The multi-function
contact input is
incorrect
1. Multi-function contact input is set to 69 and
switched on.
2. Multi-function contact input is set to 169 and
switched off
