Litepanels Gemini 2x1 Soft User Manual

10
litepanels.com
Strobe
Momentarily increase the light output level on a regular interval, for a flashing effect
LEFT
CENTER
RIGHT
TURN
HUE
Color wheel in degrees
Red = 0
Green = 120
Blue = 240
SAT
Purity of the HUE
0 = White (5600K)
100 = Pure Color
DIM
0 = No Output
100 = Full Output
TURN
RPM
Adjust the ON/OFF RATE
Eg:
30 = 30 RPM (.5HZ)
1000 = 1000 RPM (16.7HZ)
DUTY
Ratio of ON-TIME vs OFF-TIME
Eg:
40 = 40% ON, 60% OFF
60 = 60% ON, 40% OFF
BIAS
Adjust the light output
level while between
pulses
PRESS
Change Row
MODE
Select LOOP MODE
or MANUAL MODE
MANUAL MODE = Activate the
pulses with BUMP Only
LOOP MODE = Pulses repeat as
determined by OFF TIME setting
BUMP
Press to activate the
pulses manually at any
time
Notes:
The DUTY setting can be used to create non-symmetrical flashing patterns where the light is, for example,
ON for a very short portion of each time interval and OFF for a longer portion. This allows very precise
control of the flash pattern.
