Litepanels Gemini 2x1 Soft User Manual

3
litepanels.com
Emergency!
Simulates flashing lights for various types of emergency vehicles
LEFT
CENTER
RIGHT
TURN
PULSES
Select groups of
1, 2, 3, 4, 5 pulses
COLORS
Select from:
Blue; Red; Amber; Blue/Red;
Blue/Amber; Blue/White;
Blue/Red/White
DIM
0 = No Output
100 = Full Output
Fire
Simulates a wide variety of fire effects from a match to a candle to a bonfire
LEFT
CENTER
RIGHT
TURN
HUE
Color wheel in degrees
Red = 0
Green = 120
Blue = 240
SAT
Purity of the HUE
0 = White (5600K)
100 = Pure Color
DIM
0 = No Output
100 = Full Output
TURN
RATE
Adjust the flicker rate
of the flames
Eg:
1 = Slow flicker
100 = Fast flicker
DEPTH
Adjust the range of the
intensities of the flames
Eg:
0 = No change in intensity
100 = Large range in intensity
PRESS
Change Row
COLOR MIX
Select how intensity affects HUE
Eg:
1-CLR = Only selected HUE used
NARROW = Intensity affects HUE
slightly
MED = Intensity affects HUE
moderately
WIDE = Intensity affects HUE greatly
Notes:
COLOR MIX: Larger intensities lower the HUE value
RATE: Smaller values used for larger flames, larger values used for smaller flames. Ex. Candle RATE = 80
DEPTH: Smaller values used for smaller flames, larger values used for larger flames
