3.2.1 MPM DIP Switch Functions
The MPM DIP switch defaults are suitable for the majority of installations. On occasion it may
assist the operation of the system to activate some or all of the additional functionality built in
to the DIP selection. The table below details the effect each combination of DIP positions will
have on system performance.
Z-Plus MPM DIP switch functions
Function Description
DIP switch position
1 2 3 4
Factory
Default
Eight zone with the return air as the
sensor location.
OFF OFF OFF OFF
Touchpad 1
Sensor Point
System will cycle based on the temperature
at the touchpad 1 location.
ON OFF OFF OFF
Touchpad 2
Sensor Point
System will cycle based on the temperature
at the touchpad 2 location.
OFF ON OFF OFF
Sensor
Averaging
System will cycle based on an average of
both touchpad sensors .
ON ON OFF OFF
Sensor
Averaging
System will cycle based on all available
sensors.
ON ON ON OFF
Zone 1 link
:KHQ=RQHLVRQWKHV\VWHPZLOOF\FOH
exclusively on the touchpad 1 sensor.
OFF OFF OFF ON
Z-Plus MPM DIP switch functions
Function Description
DIP switch position
5 6 7 8
Zone 1 Mimic
System will be capped at 7 zones with the
eighth output set to mimic output 1.
OFF OFF OFF ON
3.2.2 Motorised Dampers
The motorised barrel dampers must all have the same motor type,
DQGVKRXOGEH¿WWHGLQOLQHLQWKHÀH[LEOHGXFW
3.3 Control Wiring
 All control wiring to touchpads and motors is by RJ12 type connectors, with the exception
of the 24 VAC supply to the Livezi Connect main modules.
 Data cables are to be kept the maximum practical distance from any LV power supply
FDEOHVYROWV0LQLPXPGLVWDQFHPP
 Maximum cable length is not to exceed 50 m.
Suggested cabling: Livezi supplies and recommends the following cable:
50&$%VL[FRUHÀDWFDEOHIRUWRXFKSDGVXQLWLQWHUFRQHQFWDQGGDPSHUPRWRUV
