User Manual for “LM068_BLE_Peri_0204” FW
iv. “AT*RESET=2”\r\n
1. LM device applies hard reset
2. Loads default settings for all configuration settings
3. LM de causes disconnection of all Bluetooth/BLE
connections
4. LM device deletes all the paired devices (Bluetooth and
BLE) and corresponding data
7.2.8 “AT*SETTINGS”\r\n
i. Query only command
ii. LM device settings query: “AT*SETTINGS=?”\r\n
iii. Report for “AT*SETTINGS=?” command is multiple line, at the end
of the report a message “REP*:SETTINGS=END” is delivered.
at*settings=?at*settings=?
OK
NAME=LM068_BLE_Adapter55
BAUD=19200(2)
STOP=Stop_One(0)
PARITY=None(0)
FLOW=OFF
ECHO=ON
RESP=ON
GAPROLE=GAP_PERIPHERAL
ADDR=Static,Public,0002-5b-555555
LE_SEC=OFF
LEBOND=0000-00-000000
VER=068LM_BLE_PERI_02.01
REP*:SETTINGS=END
7.3 UART Settings commands:
7.3.1 “AT*BAUD”\r\n
i. Query and set command
ii. Baud rate query: “AT*BAUD=?”\r\n
iii. Baud rate query report: “REP*:BAUD=19200(2)”. Number in curly
brackets shows the serial number as per below table.
iv. Baud rate set command: “AT*BAUD=3” (Set Adapter baud rate as
38400 bps)
v. LM device need not to perform power-on-off after change of baud
rate setting.
vi. Refer below table for baud rate settings:
Sr
No
Actual
baud rate
LM device
Baud rate
code
Report from LM
DEVICE
1 9600 1 “REP*:BAUD=9600(1) ”
2
19200
2
–
Default
baud rate
“REP*:BAUD=19200(2)”
