4 START UP MANUAL
HYDROBAR EXPRESS 326 S2
End of bar setting :
Important : Before handling the barfeeder, stop the lathe at the end of part cycle.
1. Press the key [STOP].
2. Press the key [MENU].
The display reads :
PARAMETERS RELATED
TO START UP
3. Press twice the key attributed to the icon [PAGE DOWN].
The display reads :
SETTINGS FOR
POSITIONING
4. Press the key attributed to the icon [ENTER].
The display reads :
POSITION OF THE END OF THE
BAR **** MM
5. Press the key attributed to the icon [SET].
Depending on which sequence the bar feed is in when the parameter is selected, the
available functions and icons can change :
Functions
Conditions
By offset correction
By teaching
- Guiding channel closed
- No bar stock in the guiding channel
icon : [+/-] icon : [TEACH IN]
- Guiding channel open
icon : [+/-]
---
[+/-] By offset correction
C Press the key attributed to the icon [+/-].
The display reads the current end of bar position.
C Enter the correction value with the numerical keys. Then, press the key attributed to
the icon [+] to add the value, or the key attributed to the icon [-] to substract it. The
display reads the new end of bar position.
C To exit the end of bar set mode, press the key attributed to the icon [ESC].
[TEACH IN] By teaching
C Press the key attributed to the icon [TEACH IN].
The display reads the current end of bar position
C Press the key [FWD] and advance the pusher to the desired position (see previous
page).
C To validate the new end of bar position, keep [ENTER] pressed until the icon
disappears.
6. To exit the set mode, press the keys [MENU] or [STOP].
