7
LOW VOLTAGE
CONNECTION
BOARD
SMA RT SYSTEM
CONTROL BOARD
ALARM BELL
LOUVER RELAY
RUN TIME CONTACTS
SEQUENCER / BUILDING
MANAGEMENT SYSTEM
W ATER HEATER PUMP
IGNITOR
BLOWER
GAS VALVE
DISPLAY PA NE L
BUILDING RECIRCULATION
PUMP
Control outputs
1 Service (continued)
