3 Troubleshooting (continued)
36
Table 3F (continued from previous page) Troubleshooting Chart - Fault Messages Displayed on Water Heater Interface
FAULT DESCRIPTION CORRECTIVE ACTION
Fan Low
OR
Fan Speed Low
(will require a manual
reset once the condition
has been corrected. Press
the RESET button on the
SMART TOUCH
display
to reset.)
The actual fan RPM is 30% lower than what
is being called for.
Vent/air intake lengths exceed the maximum allowed
lengths. Refer to the General Venting section of the
Armor Water Heater Installation and Operation
Manual for proper lengths.
Check for obstruction or blockage in the vent/air
intake pipes or at terminations.
• Check the wiring connections at the fan and at the
main control board.
Replace the fan.
Replace the main control board.
Blown fuse.
Replace fuse F4 on the control board, see page 28 of
this manual.
Fan High
OR
Fan Speed High
(will require a manual
reset once the condition
has been corrected. Press
the RESET button on the
SMART TOUCH
display
to reset.)
The actual fan RPM is 30% higher than what
is being called for.
Vent/air intake lengths exceed the maximum allowed
lengths. Refer to the General Venting section of the
Armor Water Heater Installation and Operation Manual
for proper lengths.
Check for obstruction or blockage in the vent/air
intake pipes or at terminations.
• Check the wiring connections at the fan and at the
main control board.
Replace the fan.
Replace the main control board.
Sensor Open
(will require a manual
reset once the condition
has been corrected. Press
the RESET button on the
SMART TOUCH
display
to reset.)
Either the inlet water or outlet water
temperature sensor has been disconnected.
Check the sensors and their associated wiring.
Repair or replace the sensor or wiring if damaged.
Measure the resistance of the sensors and compare
the resistance to the tables of this manual.
Replace the sensor if necessary.
