8 Documentation
Pos. No. Description Loctite Order No.
– Rotor Top complete with Shaft Ø 3 mm 97266
5 Drive Head Assembly 97257
consists of: Rotor Top and Shaft Ø 5 mm
6 Rotor Disc (2 pcs. per box)
Rotor Disc, 10 mm dia. with mounted shaft (.39 in.) 97258
Rotor Disc, 25 mm dia. with mounted shaft (.98 in.) 97259
Rotor Disc with other diameters On request!
– Mounting Bracket for stationary applicator and rotorspray 8950700
– Extension Cord for rotorspray, 2 m (6.5 ft.), 8952153
8.1 Accessories and Spare Parts
8.2 Pin Assignment of the Plug – Connection Cord Rotor
