Loepfe YarnMaster PRISMA - Installation overview

Startup
22 www.loepfe.com
YarnMaster PRISMA
4.4 Installation overview
Variant 1
External power
supply
24 V DC
LZE-6
Power supply
24 V DC
Variant 2
External power
supply
90 – 264 V AC
Variant 3
External power
supply
24 V DC
LZE-6 “Faceless”
Ethernet con-
nection
(crossover ca-
ble)
Savio control unit
Loepfe 2-wire
bus (L2B)
Spindle
computer
(machine)
Spindle adapter
(yarn clearer)
Loepfe 2-wire bus (L2B)
Sensing head
