188
(1
Availability varies according to set type (see Technical data - equipment features chapter for your TV set).
(2
On device types with Full-HD-Display (1920x1080 pixels) , UHD-signals (3840x2160 pixels) cannot be displayed.
(3
When displaying UHD signals and HDR at the same time (with colour subsampling 4:4:4) the maximum image repeat frequency on these ports decreases to 30 Hz.
(4
A colour depth is considered Deep Color from a colour depth of 10 bits.
Signals via HDMI/AV (PC IN)
The following tables shows the compatible signals your TV set can display via the HDMI ports (HDMI1, HDMI2, HDMI3, HDMI4
(1
) or using
an appropriate adapter in the AV (PC IN) port.
Configure the output signal of the device connected to the TV so that it matches one of the signals in the table.
Note that not all signals can be shown on each HDMI socket/AV (PC IN). On TV-set models with Full-HD-Display (1920x1080 Pixels) , UHD-
signals (3840x2160 Pixels) cannot be displayed.
In SL4xx-units, the compatible mode for the HDMI 1-3 port is enabled by default. In HDR-enabled TV-sets, the compatible mode must be
switched off to use HDR (System settings - Connections - HDMI - Compatible mode), also see Chapter System settings, Section
Connections - HDMI.
HDMI 1
LCD-TV-sets
(Chassis SL3xx)
LCD-TV-sets
(Chassis SL4xx)
OLED-TV-sets
(Chassis SL4xx)
Resolution: Image frequency:
640x480 60Hz
zzz
720x480p 60Hz
zzz
720x576p 50Hz
zzz
1280x720p 50 / 60Hz
zzz
1920x1080i 25 / 30Hz
zzz
1920x1080p 24 / 25 / 30Hz
zzz
1920x1080p 50 / 60Hz
zzz
3840x2160p 24 / 25 / 30Hz z
(2
z
(2
z
3840x2160p 50 / 60Hz z
(2
z
(2
z
Bandwidth: 300Mhz 450Mhz 450Mhz
Resolution/ Image frequency: Sampling rate: Colour depth:
(4
Colour depth:
(4
Colour depth:
(4
3840x2160p @ 24 / 25 / 30Hz 4:4:4 8bit 8bit / 10bit / 12 bit 8bit / 10bit / 12 bit
3840x2160p @ 24 / 25 / 30Hz 4:2:2 8bit 8bit 8bit
3840x2160p @ 50 / 60Hz 4:4:4
———
3840x2160p @ 50 / 60Hz 4:2:2
———
3840x2160p @ 50 / 60Hz 4:2:0 8bit 8bit / 10bit / 12 bit 8bit / 10bit / 12 bit
HLG / HDR 10 / Dolby Vision:
— / — / —
z
(3
/ z
(3
/ — z
(3
/ z
(3
/ —
ARC:
zzz
HDMI 2
LCD-TV-sets
(Chassis SL3xx)
LCD-TV-sets
(Chassis SL4xx)
OLED-TV-sets
(Chassis SL4xx)
Resolution: Image frequency:
640x480 60Hz
zzz
720x480p 60Hz
zzz
720x576p 50Hz
zzz
1280x720p 50 / 60Hz
zzz
1920x1080i 25 / 30Hz
zzz
1920x1080p 24 / 25 / 30Hz
zzz
1920x1080p 50 / 60Hz
zzz
3840x2160p 24 / 25 / 30Hz z
(2
z
(2
z
3840x2160p 50 / 60Hz z
(2
z
(2
z
Bandwidth: 300Mhz 450Mhz 450Mhz
Resolution/ Image frequency: Sampling rate: Colour depth:
(4
Colour depth:
(4
Colour depth:
(4
3840x2160p @ 24 / 25 / 30Hz 4:4:4 8bit 8bit / 10bit / 12 bit 8bit / 10bit / 12 bit
3840x2160p @ 24 / 25 / 30Hz 4:2:2 8bit 8bit 8bit
3840x2160p @ 50 / 60Hz 4:4:4
———
3840x2160p @ 50 / 60Hz 4:2:2
———
3840x2160p @ 50 / 60Hz 4:2:0 8bit 8bit / 10bit / 12 bit 8bit / 10bit / 12 bit
HLG / HDR 10 / Dolby Vision:
— / — / —
z
(3
/ z
(3
/ — z
(3
/ z
(3
/ —
ARC:
———

