GB-54
Preparation Connections Initial Setup Using the Features DVR (Digital
Video Recorder)
Using the Features
via USB port
Using the DVD
Features
Hints and Tips, Specification
and Safety Warnings
Specification
Model L19DVDB10
Panel System 18.5 inch LCD panel
Display Resolution
1366 pixels (horizontal) x
768 pixels (vertical)
Television System PAL I/BG/DK, SECAM L/BG/DK
Brightness 230-300 cd/m
2
Contrast Ratio 800-1000:1
Inputs/Output
SCART 1
HDMI 1
VGA 1
PC AUDIO 1
S-VIDEO 1
YPbPr 1
CI 1
USB 1
DVD 1
VIDEO IN (RCA) 1
AUDIO IN (RCA) 1 (L + R)
COAXIAL 1
RF (75 Ω) 1
Speaker Power 3 W + 3 W
Earphone (3.5mm) 1
Power Source 100V-240V~50/60Hz
Dimension( W x D x H) with base 460 x 170 x 344 mm
Weight (Net) 4.7 kg
Features and Specifications are subject to change without notice.
