GB-6
Preparation Connections Initial Setup Using the Features DVR (Digital
Video Recorder)
Using the Features
via USB port
Using the DVD
Features
Hints and Tips, Specification
and Safety Warnings
Front / Top / Side View and Controls
Item Description
1 POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate blue when the timer programming has started in the
standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3
Press to insert and eject disc. (DVD mode)
4
Press to start playback or pause. (DVD mode)
5 VOL +/-
Adjust the volume.
Select and adjust a setting in the OSD menus.
6 CH +/-
Select a channel.
Select a sub-menu of the OSD menu.
7 MENU Displays the OSD (on screen display) menu.
8 SOURCE
Select among the different input signal sources:
DTV / TV / DVD / AV / S-VIDEO / SCART / YPBPR / HDMI / PC
9
/ I
Switch the TV on from standby.
Switch the TV back to standby.
10 Disc Slot
Insert the disc with the mirror side facing towards you (12 cm discs only. Don’t insert 8
cm discs)
11 POWER ON/OFF Switch on the POWER ON/OFF switch to turn the TV to standby mode.
1 2
5
10
11
6 8 9743
To Next Page
