10. Place the bottom hole of the lower door
onto the bottom hinge pin. Insert the
middle hinge pin into the upper hole of
the lower door. Tighten the pin securely.
Screw the middle hinge tightly. Cover the
remaining holes with the hole covers.
11. Place the bottom hole of the upper door
onto the middle hinge pin. Reverse the
upper hinge. Insert the upper hinge pin
into the upper hole of the upper door.
Tighten the pin securely. Screw the upper
hinge tightly. Cover the upper hinge with
the upper hinge cover for left side.
Ensure the lower door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before nally tightening the hinge.
Ensure the upper door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before nally tightening the pin.
In some cases, the door seal may be crushed after prolonged storing pressure,
resulting to the door seal not able to close properly when reversed.
Follow the steps below to solve the issue:
• Peel o the door seal from the upper or lower corner
and warm it with a hairdryer; the warmth can allow
the door seal to return to its original form. Do not
blow directly on the unit as the warmth may damage
other parts of the unit.
• Rotate the door seal upside down so that the side
originally with the hinge stay with the hinge.
• Insert the door seal back into the door from the upper
or lower corner.
• If the issue still occurs, contact your local service centre for assistance.
180°
