Location
When selecting a position for your unit you should make sure the oor is at and rm, and
the room is well ventilated with an average room temperature of between 10°C and 43°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the
unit.
If the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
Make sure the levelling feet are well secured to the oor to
prevent movement of the appliance.
In case the upper doors are not aligned, you can
level them by inserting the washers:
1. Raise the upper door slightly.
2. Use a plier to insert the washer in between the
middle hinge and upper door.
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm at
the rear and 25 mm at the top of the unit.
Please ensure there is more than twice the
width and depth distance space of the unit
to fully open the door.
Y mmY mm
X mmX mm
9
