2.0 There must be a current supply
2.1 Battery specifications
The manufacturer offers three different battery types recommended
for EHL 1004:
Note 1: Battery life: 300 cycles at 80% = approx. 600 cycles at 50%
Note 2: Longest battery life obtained when the battery is charged on being 80%
discharged. 1 charge = 1 cycle
Note 3: Charging voltage of 14.4 V or higher will damage the battery.
Note 4: The battery can be charged, irrespective of how much it is discharged.
Battery life: 600 cycles at 60%. To avoid shortening the life of the battery, it
should never be discharged to more than 25%.
Dry-charged batteries must be filled with battery acid 37.5% H
2
SO
4
specific gravity 1.28
before they are used for the first time.
Semi-trak
986034
Tubular cell
986024
Maintenance free
986040
Voltage 12 V 12 V 12 V
Capacity 60Ah/5h 56Ah/5h 50Ah/5h
Recommended for Normal use Severe daily use
Where maintenance
work is not desired
Life in cycles at
80% discharge
Approx. 300
-See note 1
Approx. 1200
-See note 2
Approx. 800
-See note 4
Maintenance
Liquid inspection
Acid level must be min. 5 mm and max. 10 mm
above cells. Add distilled water if necessary
None
Maintenance
Poles
Verdigris to be removed from poles regularly. Poles to be greased
after cleaning.
Charge condition to
be measured with:
Acidometre, voltmetre or
electrical capacity metre.
Voltmetre or
capacity metre
Charging frequency
Daily or as required.
-See note 1
At 80% discharged
battery. -See note 2
Daily or as required
-See note 4
Charging voltage
measured accross
poles during charging
15,2 V 15,2 V 14,2 V
(See note 3)
No. of lifts with
correct usage.
Load 500 kg
175 lifts 170 lifts 170 lifts
Load 1000 kg 50 lifts 50 lifts 50 lifts
Battery dimensions
LxBxH
278x175x190
19,8 kg
271x172x225
21 kg
275x175x190
20 kg
