logitrans LOGIFLEX SELF 1001 - Controller Comments

6
Electronic control - Comments Electric system
Comments:
1. Maximum speed Governs the power directed to the motor in % of maximum power.
This leads to a given wheel speed depending on load. 100% is 6 km/h, with no
 loadandonaatsurface.
2. 1st reduced power Governs the reduced effect sent to the motor. Is not functional when the value
is 100%.
This function can be used to set an extra top speed (lower than true top speed)
selected and deselected by a switch. When the switch is open the top speed is
reduced. When the switch is closed the top speed is equal to the maximum
speed as above. The switch must be connected to the positive pin and pin 14 of
the 15-pin socket (see circuit diagram). The speed available is not proportional
to the power used, e.g. 34% is approximately 3 km/h with no load. This
 parameterisusedonSELFtoreducethemaximumspeedto3km/hwhenthe
forks are raised higher than 50 cm.
3. 2nd reduced speed Not used.
4. Minimum power The power the truck starts with when the drive grip is turned.
5. Safety forward power The maximum power sent to the motor when the safety switch is activated.
Acceleration is the same as normal operation (see point 7).
6. Maximum power The maximum power sent to the motor upon starting. A reduction of this will
give less tractive power.
7. Acceleration slope The time difference from no power to full power when the drive grip is turned
full extent.
8. Maximum temperature The maximum internal temperature of the controller. If this value is reached
the controller will shut down. After a short cooling period operations may be
resumed.
9. Safety forward time The time the vehicle can drive (forwards) when the safety switch is activated.
10. Battery 90% The voltage of the battery when 90% charged. The controller loads the battery
and measures in fractions of a second when the truck starts to move.
11. Battery 70% As above.
12. Battery 50% As above.
13. Battery 25% As above.
14. Battery 15% As above.
15. Battery charg. voltage When this voltage is exceeded, the counter “No. of charges” increases by one
(see point 20). At the same time, the “subtotal counter“ is zeroed (see point 19).
16. A/D start voltage The voltage given by the Hall effect units to start moving.
