Logosol E5000 - Table of Contents; Safety Rules

1
Safety rules
• The LOGOSOL E 5000 may only be used for cross
cutting in combination with the LOGOSOL mini-saw
mill. Incorrect use can cause severe injury. Always
concentrate fully and work carefully with the sawing
unit.
•Attach support legs under the saw mill guide rail
before you attach the sawing unit. Otherwise the saw
mill may tip over when there is no load on the log bed.
•Do not wear loose clothing, scarves and the like which
can get caught in the saw.
•Always check that the saw is solidly tted on the guide
rail before plugging in the cable. In order to prevent
the saw from pitching off the guide rail when started,
ensure that both plastic strips attach rmly to the
guide rail ange.
Contents
Safety rules 1
Assembly 2
Assembling bar and chain 3
Chain lubrication 4
Frame support 5
Control light and electric system 6
Cutting equipment 6
Maintenance 7
Belt tension 7
Schematic 8
Parts list 9
Circuit diagram 10
Technical specications 11
EU manufacturer’s declaration 11
For your own safety, read all safety precau-
tions carefully and do not start the machine
before you have understood all of them. Do
not allow persons who have not read the
safety instructions to operate the machine.
You should also read the instruction manu-
als for the LOGOSOL sawmill.
Use approved hearing protection and safety
glasses. Even short exposures to high-fre-
quency sounds can damage your hearing.
Use gloves when you work with the chain,
as there is a danger of cutting yourself.
Rotating saw chain: do nor insert ngers
under the chain protective cover or past the
saw mill guide rail. Always stand behind the
control arm while sawing.
• Check that the electric cable runs free along the entire
sawing bed. Do not step on the cable.
•Turn the saw off after each cut.
•In order to prevent unauthorized use, never leave the
saw unattended when plugged in.
•Pull the plug out
- before replacing, adjusting and cleaning thechain, or
carrying out any other maintenance.
-before touching any moving parts.
- before removing the saw from the saw mill.
