Logosol SMART SET - ASSEMBLY: BOX-DV (PART 2); Step 8: Trailer Kit Mounting; Step 9: Chain Tightening; Step 10: Chain Connection

16
BOX-DV
2 x – M6x30
4 x – M6
04-00443
2 x – M10
8
9
10
01-00421
Trailer kit
Extension chain 01-00421 is required when
mounting a trailerkit to the rail.
Tighten the supply chain manually as
much as possible before it is mounted
on the chain lock.
